AM76ix series
Print, Copy, E-mail, and Scan with the Avision AM76ix series
We’ve taken the office-critical features of our large departmental MFPs and packed them into this ultra-productive A3-size printer. It seamlessly integrates print, scan, e-mail, and copy functionality. All these features are operated through a clear and large 10” LCD touch screen to simplify work for busy offices with high-volume of document distribution. What is best, with the intelligent “Drop N Take” and “ID card authentication” features, your copy job can be done easily and securely.
Product Detail
Product Features
Unique auto crop / deskew and blank page removal feature
The Avision’s innovative intelligent copy allows you to insert your document easily to the feeder or on the glass platen, and then the next second a perfect copy can be done automatically. If a document is not inserted correctly, the image can be automatically cropped and straightened during scanning. Plus, with the blank page detection and removal feature, the blank page can be detected and deleted without being printed. All these features let you complete your copy efficiently and effectively.
No More Trouble to Place Documents on the Feeder/Platen Glass
The intelligent “Drop N Take” feature allows you to simply load your document easily to the feeder or on the glass then the next second your copy is automatically straightened. It is simply that easy without having to press any button!
Two reading heads save twice working time
Featuring two reading heads, the product is able to achieve two-side (front and read side) scanning in one scan, meaning the page does not need to pass through the feeder twice to save your working time.
Easy-to-use via the simple user interface
Easy to read and navigate, the large 10-inch, bright color touch screen guides you through even the most complex operations. Simply make a few touches on the touch screen, your document can be digitized and distribute within seconds.
Preview your copy result on screen Lets you verify your result and choose which side you want to copy.
Advanced scanning capabilities
The product lets you scan paper-based documents in full color in PDF, JPEG, or TIFF file format and send them to a variety of destinations such as E-mail, FTP, USB and network folder (SMB).
Convenient mobile printing, and scanning
Wirelessly print, or scan from your mobile devices through Avision’s app for the MFPs.
Convenient walk-up printing and scanning
A USB direct interface is available for printing files from or scanning files to your USB flash memory drive.
Easy customization based on Android system
Based on Android operating system, the AM76ix series provides convenience to customize your workflow so that your work is easy to be done.
Automatic two-sided printing
Allows you to print on both sides of the page, cutting your paper use by up to 50%.
High-yield toner cartridge
The AM76ix series is shipped with easy-to-install, high-yield 35,000-page toner cartridges that deliver a low cost per page.
High-capacity paper tray
With a main capacity of 530 sheets and expandable to 2,220 sheets, Say goodbye to frequent paper refills, ensuring seamless workflow and increased efficiency.
Get a perfect ID card copy from the AM76ix series
No need to align your card.The AI image processing technology automatically detects, rotates, crops, and straighten your images. Plus, a few popular layouts have been provided for various requirements.
Control access to MFPs by ID card
The AM76ix series provides a secure way to access the machine by ID cards. By scanning the ID card on the control panel, administrators can assign usage privileges quickly and easily. The solution is designed for companies with many different departments, all with individual needs and offices concerned with reducing waste and tightening security.
Technical Specifications
| printer-Functions | Copy – Print – Scan – Network |
|---|---|
| printer-CPU | 1.2GHz |
| printer-RAM | 2 GB |
| printer-Display | Up to 10" Touch Panel |
| printer-Duplex printing unit | Automatic |
| printer-Duplex print | Paper size:A3, A4, B4(JIS), A5, B5(JIS), A6, B6(JIS), Letter, Legal, Ledger;Paper weight:60 to 105 g/m² |
| printer-Connectivity | USB 2.0, Wi-Fi(optional), 10/100/1000 Base-T Ethernet |
| printer-Dimensions (WxDxH) | AM7630ix:575 x 602 x 686 mm (22.6 x 23.7 x 27 in.);AM7640ix-AM7650ix:575 x 602 x 799 mm (22.6 x 23.7 x 31.5 in.) |
| printer-Weight | AM7630ix:38 kg (84 lb.);AM7640ix-AM7650ix:45 kg (99 lb.) |
| printer-Power Supply | 100-120 VAC, 60 Hz or 220-240 VAC, 50/60 Hz |
| printer-Paper output capacity | 500 sheets |
| printer-Standard support Paper Capacity | 630 sheets ( AM7630ix );1,160 sheets ( AM7640ix-AM7650ix ) |
| printer-Maximum support Paper Capacity | 2,220 sheets |
| printer-Paper capacity(Manual tray) | 100 sheets ( 70 g/m2 plain paper ) |
| printer-Paper size(Manual tray) | A4, B5(JIS), A5, A6, letter, Legal, B4(JIS), A3, Ledger, B6(JIS) |
| printer-Paper weight(Manual tray) | 60 to 163 g/m² |
| printer-Paper capacity(Tray 1 and tray 2) | 530 sheets(70 g/m² plain paper) |
| printer-Paper size(Tray 1 and tray 2) | A4, A5, A6, B5(JIS), Letter, Legal, A3, B4(JIS), B6(JIS), Ledger |
| printer-Paper weight(Tray 1 and tray 2) | 60 to 105 g/m² |
| printer-Paper capacity(Tray 3 and tray 4 (option)) | 530 sheets(70 g/m2, plain paper) |
| printer-Paper size(Tray 3 and tray 4 (option)) | A3, A4, B4(JIS), A5, B5(JIS), A6, B6(JIS), Letter, Legal, Ledger |
| printer-Paper weight(Tray 3 and tray 4 (option)) | 60 to 105 g/m² |
| printer-Printing Method | LSU |
| printer-Printing Speed | AM7630ix:30 ppm (A4 LEF);AM7640ix:40 ppm (A4 LEF);AM7650ix:50 ppm (A4 LEF) |
| printer-Maximum media size | 297 x 420 mm |
| printer-Minimum media size | 100 x 148 mm |
| printer-Resolution | 1200 x 1200 dpi |
| printer-PDLs/Emulations | PCL / PS / GDI |
| printer-Supported operation system | Linux, Win 11 , Win 10 , Win 8 , Win 7, Mac |
| printer-First print output time | < 9sec. |
| printer-Copy Size | A3, A4, B4(JIS), A5, B5(JIS), A6, B6(JIS), Letter, Legal, Ledger |
| printer-Copy Speed | AM7630ix:30 cpm (A4 LEF);AM7640ix:40 cpm (A4 LEF);AM7650ix:50 cpm (A4 LEF) |
| printer-Max scanning size | A3 ( Ledger at ADF) |
| printer-Min media size | 100 x 148 mm |
| printer-Copy Resolution | 600 x 600 dpi |
| printer-Copy Count | 999, Auto Reset to 1 |
| printer-intelligent copy | auto crop / autodeskew / auto blank page removal |
| printer-Flatbed auto paper size detection | LIR, A4, LGL, A3 |
| printer-ADF auto paper size detection | DLT, A3, LG, B4(11S), A4 SEF, A4 LEF, A5SEF,A5LEF,B5(JIS) SEF, B5(JIS) LEF, LT LEF |
| printer-Auto Paper Tray Select | Yes |
| printer-Zoom | 25 % ~ 400 % |
| printer-Full Page Copy | Yes |
| printer-N-up Copy | 2 in 1 / 4 in 1 / ID Card ( N-up Copy ) |
| printer-Duplex Copy | Booklet, Calendar |
| printer-Copy Sides | 1->1, 2->1, 1->2, 2->2 |
| printer-Density | Level 1-7 |
| printer-Technology | CMOS-CIS |
| printer-Optical resolution | Up to 600 x 600 dpi |
| printer-Scan speed(ADF) (A4@300 dpi) | 80ppm / 160ipm |
| printer-File Formats | JPEG, PDF, TIFF |
| printer-Scanning features | Network Scan, Scan to USB Disk / FTP / SMB / E-mail / Webpage |
| printer-ADF Capacity | 100 sheets |
| printer-Paper Thickness and Weight | 60 ~ 105 g/m2 (16 ~ 28 lb.) |
| printer-Toner Cartridge | 35,000 sheets(A4, 5% cover rate) |
| printer-Drum Unit | 300,000 sheets |
| printer-Development Unit | 300,000 sheets |
| printer-Fusing Unit | 300,000 sheets |
